ONGO N290JD Thin Wall Box Plastic Injection Molding Machine

The ONGO N290JD is a horizontal injection molding machine with a clamping force of 290 tons, specifically designed for the high-speed, large-scale production of thin-walled plastic products such as food containers, logistics thin-walled storage boxes, and packaging thin-walled boxes. With high-speed molding, precision shape control, energy saving and high efficiency as its core advantages, it is a professional core equipment for the mass production of thin-walled plastic boxes in the food packaging, logistics packaging and other fields.

Size:

6.65x1.8x2.35 M

Place of Origin:

China

Minimum order quantity:

Color:

Blue&White

Material Science:

PP,PVC,PET,HDPE,PC,ABS

Delivery time:

30 days

Model:

N290JD

Transaction mode:

T/T

Inquiry

Write a Review

Product Introduction

ONGO persistent advanced injection molding technology is introduced into the market, in close cooperation with customers,we constantly seek solutions in mechanical engineering and forming technology.ONGO N290JD thin wall box plastic injection molding machine to enhance the design platform, in the short period of rapid prototyping machine for oil spill, mechanical life, etc.problems are significantly improved. And the use of modern processing technology, advanced injection control mode, to ensure that the overall response to high efficiency, high performance stability.ONGO N290JD thin wall box plastic injection molding machine of excellent performance, widely used in plastic processing industry, especially for thin–walled products, multi cavity mold, and traditional industries provided effect yield significantly.

Product drawing

Product details
Thin Wall Box Plastic Injection Molding Machine

Platen dimensions

Mould space dimensions

Mould space dimensions

PRODUCT ADVANTAGE

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 18

Injection cylinder double rod

Special injection piston rod design, the force balance, Can prolong the use time of oil seal oil seal. Significantly reduce the amount of oil back to the high speed of injection, So as to reduce the oil resistance of injection.

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 19

Injection speed

Parallel movement and high–speed/low presure injection movement that shortens circle time,especially for thin wall products.

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 20

Low low friction design

The injection unit used linear guide , to minimize the friction and increase speed during injection

New design enhanced template

Improved platen with high rigidity structure,especially suit to thin–wall products.

Tie bar

The tension rod is made of alloy steel and strengthening design , to extend the service life of high speed running condition.

Screw&barrel

Can be optional infrared thermal insulation device,has the advantages of fast heating, energy saving,long life and other advantages, to further enhance the plasticization quality.

Product features

With CANbus EtherCAT bus communication, the computer system is full digital controlled.The temperature control adopts special control module. The accuracy can achieve 1 degree.With the power monitoring function, it can monitor the current energy consumption during the production.

Product details

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 25

The electric storage adopts the high-end direct-drive structure,which has low maintenance cost, durability, high storage accuracy and can save 15% - 25% electricity.

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 26

Standard water-oil separator is equipped to reduce gas valve jamming and improve injection quality.

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 27

Controlled by the proportional direction valve, the movement can accelerate quickly.During the high speed running, it can operate steadily and precisely control the mold open position.

ONGO N290JD Thin Wall Box Plastic Injection Molding Machine 28

The hydraulic system adopts double servo drive control. It has the advantages of high efficiency, energy saving and low noise.Meanwhile, it can realize mold-open and charge synchronization function.

The electric storage adopts the high-end direct-drive structure,which has low maintenance cost, durability, high storage accuracy and can save 15% - 25% electricity.

Standard water-oil separator is equipped to reduce gas valve jamming and improve injection quality.

Controlled by the proportional direction valve, the movement can accelerate quickly.During the high speed running, it can operate steadily and precisely control the mold open position.

The hydraulic system adopts double servo drive control. It has the advantages of high efficiency, energy saving and low noise.Meanwhile, it can realize mold-open and charge synchronization function.

Product Specifications

Name: Atypical Snack - Box

Material: PP

Major Products: Multiple Squares、Non Standard Snack - Box

Mold:Two cavities

Machine Model: N290

Molding Cycle: About 5.2s

8 (4)

7 (6)

6 (7)

5 (5)

Product parameters

ITEM		N290
INJECTION UNIT
Screw Diameter	mm	45
Screw L/D Ratio	L/D	25
Shot Volume(theoretical)	cm³	397
Injection Weight(ps)	g	362
Injection Speed	mm/s	317
Injection Rate	g/s	458
Injection Pressure	MPa	190
Screw Speed	rpm	400
Injection and Displacement force	KN	84
Injection stroke	mm	250
CLAMPING UNIT
Clamping Force	kN	2900
Open Stroke	mm	545
Space Between Tie Bars(WxH)	mm	580*580
Max.Mould Height	mm	550
Min.Mould Height	mm	250
Ejector Stroke	mm	150
Ejector Force	kN	70
OTHERS
Max.Pump Pressure	MPa	16
Pump Motor Power	kW	54
Heating Power	kW	16.5
Machine Dimension(LxWxH)	m	6.11.82.2
Oitank Cubage	L	380
Machine Weight	T	12
